This Canon imagePROGRAF iPF6100 Service Manual has been issued by Canon Inc. for qualified persons to learn technical theory, installation, maintenance, and repair of products. This manual covers all localities where the products are sold. For this reason, there may be information in this manual that does not apply to your locality. This manual may contain technical inaccuracies or typographical errors due to improvements or changes in products. When changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition of this manual.
The descriptions in this Canon imagePROGRAF iPF6100 Service Manual are subject to change without notice for product improvement or other purposes, and major changes will be communicated in the form of Service Information bulletins. All service persons are expected to have a good understanding of the contents of this Service Manual and all relevant Service Information bulletins and be able to identify and isolate faults in the machine."
This printer is a large-format printer that prints in a maximum width of 44 inches with high-speed photographic picture quality. This printer is a stand-mounted type printer and is capable of output to either roll media or cut sheet. The printhead that mounts on the carriage is an integrated six-color disposable printhead. It has 2,560 nozzles for each color, comprising two trays of 1,280 nozzles each arranged in a zigzag pattern. If print quality remains unimproved even after a specified cleaning operation, replace the printhead. Replacement about one year after the date of initial unpacking is also recommended.
The ink tanks come with 12 colors: mat black (MBK), black (BK), photocyan (PC), cyan (C), photomagenta (PM), magenta (M), yellow (Y), red (R), blue (B), green (G), gray (GY) and photogray (PGY). Each of these inks are pigment ink. The tanks are also available in two capacities: 330 mL and 700 mL. Each tank is furnished with a notch for preventing incorrect installation, which will allow the tank to be installed only at the position marked in the right color. An ink tank should be replaced when an ink tank replacement prompt message appears or when six months expire after the date of initial unpacking, whichever occurs earlier.
Canon imagePROGRAF iPF6100 Service Manual tables of content : product description, technical reference, installation, disassembly and reassembly, maintenance, troubleshooting, service mode, error code.
Download Canon imagePROGRAF iPF6100 Service Manual here
